30171CO Secura

KSQ’S 30171CO Secura is a digital locker lock with mifare card reader. The 30171CO Secura offers contactless operation as the striker plate features a spring loaded door plunger to assist users with opening the door when the correct card is presented.

30171CO Secura features a high quality Mifare card reader with read range up to 30mm. Features a modern slimline card reader offering both public user mode and private user modes. Compatible with all Mifare 1K 13.56 MHz cards, fobs, and wristbands. Black gloss card reader face with satin silver zinc alloy chassis, white ABS Body and battery compartment, anti-friction roller striker plate with a spring-loaded plunger to ‘pop door open’ when unlocked and, an Emergency Power Bank with Micro-USB connecting cable.

Emergency power device and mifare master cards supplied FOC with orders of 50+ locks.



Category:

Description

Type

  • Digital retractable latch lock

Material, Colour & Mounting

  • Alloy and steel, satin chrome
  • Suits timber, plastic, or metal lockers and doors

Combination

  • Card, fob, wristband

Batteries

  • 4 x AA alkaline batteries for up to 12 months of operation (not included)

Locking mechanism

  • Latch locking operation

Features

  • 13.56MHz classic 1K RFID Mifare reader (card, fob, wristband)
  • Up to 3 master override RFID cards, fobs, wristbands
  • Micro USB emergency power port
  • Micro-USB power bank cable included
  • Automatic low battery prompts
  • Easy push to close and lock without card (private mode only)
  • Private assigned or public share users modes

Optional

  • Batteries
  • Emergency power bank
Weight 0.150kg
Dimensions 120mm High x 550mm Wide x 1050mm Deep



Permanent and Public user modes
Master Override Card
up to 20 User Cards Per Lock
Low Voltage Alarm
Anti Tamper Alarm
Emergency Power Input
Visual In-Use Indicator
Powered by 4 AA Alkaline Batteries for up to 5,000 operations (batteries not included)
